Intergrating a simulator ecommerce site with mysql, redis

Based on the last session, on database mysql. we came up with a simulator database for an ecommerce site:

the schema is as follow:

Entities: products, orders and order_items

sql
-- Create database if not exists
CREATE DATABASE
IF NOT EXISTS ecommerce;
USE ecommerce;


-- Products table
CREATE TABLE products
(
    id VARCHAR(24) PRIMARY KEY,
    -- MongoDB ID format
    name VARCHAR(255) NOT NULL,
    description TEXT,
    price DECIMAL(10, 2) NOT NULL,
    stock INT NOT NULL DEFAULT 0,
    category VARCHAR(100),
    image_url VARCHAR(255),
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    updated_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP
    ON
    UPDATE CURRENT_TIMESTAMP,
    INDEX idx_product_name (name),
    INDEX idx_product_category (category)
    );


    -- Orders table
    CREATE TABLE orders (
    id VARCHAR(24) PRIMARY KEY,  -- MongoDB ID format
    total_amount DECIMAL(10, 2) NOT NULL,
    status ENUM('pending', 'processing', 'completed', 'cancelled') DEFAULT 'pending',
    shipping_address_street VARCHAR
    (255),
    shipping_address_city VARCHAR
    (100),
    shipping_address_state VARCHAR
    (100),
    shipping_address_zip VARCHAR
    (20),
    shipping_address_country VARCHAR
    (100),
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    updated_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP ON
    UPDATE CURRENT_TIMESTAMP,
    INDEX idx_order_status (status),
    INDEX idx_order_created (created_at)
    );


    -- Order items table (for order-product relationship)
    CREATE TABLE order_items
    (
        id INT
        AUTO_INCREMENT PRIMARY KEY,
    order_id VARCHAR
        (24) NOT NULL,
    product_id VARCHAR
        (24) NOT NULL,
    quantity INT NOT NULL,
    price DECIMAL
        (10, 2) NOT NULL,
    created_at TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    FOREIGN KEY
        (order_id) REFERENCES orders
        (id) ON
        DELETE CASCADE,
    FOREIGN KEY (product_id)
        REFERENCES products
        (id),
    INDEX idx_order_items_order
        (order_id),
    INDEX idx_order_items_product
        (product_id)
);


-- Trigger to reduce product stock when order item is inserted
DELIMITER //
        CREATE TRIGGER after_order_item_insert
AFTER
        INSERT ON
        order_items
        FOR
        EACH
        ROW
        BEGIN
            UPDATE products
    SET stock = stock - NEW.quantity,
        updated_at = CURRENT_TIMESTAMP
    WHERE id = NEW.product_id;
        END
        //


        -- Trigger to restore product stock when order is cancelled
        CREATE TRIGGER after_order_cancel
AFTER
        UPDATE ON orders
FOR EACH ROW
        BEGIN
            IF NEW.status = 'cancelled' AND OLD.status != 'cancelled' THEN
            UPDATE products p
        INNER JOIN order_items oi
            ON p.id = oi.product_id
            SET p
            .stock = p.stock + oi.quantity,
            p.updated_at = CURRENT_TIMESTAMP
        WHERE oi.order_id = NEW.id;
        END
        IF;
END//


        -- Trigger to validate stock before order item insertion
        CREATE TRIGGER before_order_item_insert
BEFORE
        INSERT ON
        order_items
        FOR
        EACH
        ROW
        BEGIN
            DECLARE available_stock INT;


        SELECT stock
        INTO available_stock
        FROM products
        WHERE id = NEW.product_id;


        IF available_stock < NEW.quantity THEN
        SIGNAL SQLSTATE '45000'
        SET MESSAGE_TEXT
        = 'Insufficient stock available';
        END
        IF;
END//


DELIMITER ;


        -- Create a view for order summaries
        CREATE VIEW order_summaries
        AS
            SELECT
                o.id,
                o.status,
                o.total_amount,
                o.created_at,
                COUNT(oi.id) as total_items,
                GROUP_CONCAT(p.name SEPARATOR ', '
        ) as products
FROM orders o
LEFT JOIN order_items oi ON o.id = oi.order_id
LEFT JOIN products p ON oi.product_id = p.id
GROUP BY o.id;


        -- Indexes for performance optimization
        CREATE INDEX idx_product_price ON products(price);
        CREATE INDEX idx_order_date_status ON orders(created_at, status);


        -- Sample insert statements for testing
        INSERT INTO products
            (id, name, description, price, stock, category)
        VALUES
            ('507f1f77bcf86cd799439011', 'Test Product 1', 'Description 1', 29.99, 100, 'Electronics'),
            ('507f1f77bcf86cd799439012', 'Test Product 2', 'Description 2', 39.99, 50, 'Books');


        INSERT INTO orders
            (id, total_amount, status)
        VALUES
            ('507f1f77bcf86cd799439013', 29.99, 'pending');


        INSERT INTO order_items
            (order_id, product_id, quantity, price)
        VALUES
            ('507f1f77bcf86cd799439013', '507f1f77bcf86cd799439011', 1, 29.99);
ERD Diagram for simulator ecommerce:
A visual depiction of what is being written about
The features and the flow

so we will use node to create an api route in which we will perform http methods to manipulate products, orders and order_items It works like this one can list a product then create an order for the cloth then list cloth_items for the respective order.

Intergration of the database with a node express backend

first create a directory:

bash
mkdir commerce
cd commerce

Project Structure:

A visual depiction of what is being written about

Initalize npm:

bash
npm init -y

Install the required dependencies:

bash
npm install dotenv express mysql2 nodemon redis swagger-ui-express swagger-jsdoc swagger-autogen
Setup the database connections:

Mysql setup with mysql2:

javascript
require("dotenv").config();


// config/database.js
const mysqlConfig = {
  host: "localhost",
  user: "root",
  password: process.env.MYSQL_PASSWORD,
  database: "ecommerce",
  port: 3306,
  // Optional but recommended settings
  waitForConnections: true,
  connectionLimit: 10,
  queueLimit: 0,
};


module.exports = { mysqlConfig };

Redis for caching setup

javascript
// config/redis.js
const redisConfig = {
  url: "redis://localhost:6379",
  // Optional configuration
  socket: {
    connectTimeout: 10000,
  },
};


module.exports = { redisConfig };

setup your environment variables:

plain text
MYSQL_PASSWORD = "your mysql password"
PORT = 8000
REDIS_URL = "redis://localhost:6379"
Create your server

setup your index/server.js

javascript
const express = require("express");


const app = express();
const PORT = process.env.PORT || 8001;


app.use(express.json());


app.get("/", function (req, res) {
  res.send("Hello, World!");
});


app.listen(PORT, () => {
    console.log(`Server running on port ${PORT}`);
  });

to run the server, either configure your package.json or run:

bash
node index.js or nodemon index.js

now that your server is running: setup your index.js

javascript
// server.js
const express = require("express");
const mysql = require("mysql2/promise");
const redis = require("redis");
const { mysqlConfig } = require("./config/database");
const { redisConfig } = require("./config/redis");


const app = express();
const PORT = process.env.PORT || 8001;


app.use(express.json());


async function initializeDatabases() {
  try {
    const mysqlConnection = await mysql.createConnection(mysqlConfig);
    console.log("MySQL connected successfully");


    const redisClient = redis.createClient(redisConfig);
    await redisClient.connect();
    console.log("Redis connected successfully");


    return { mysqlConnection, redisClient };
  } catch (error) {
    console.error("Database connection error:", error);
    process.exit(1);
  }
}


app.get("/", function (req, res) {
  res.send("Hello, World!");
});


async function startServer() {
  const { mysqlConnection, redisClient } = await initializeDatabases();


  const productRoutes = require("./routes/products")(
    redisClient,
    mysqlConnection
  );
  // const orderRoutes = require("./routes/orders")(redisClient, mysqlConnection);


  app.use("/api/products", productRoutes);
  // app.use("/api/orders", orderRoutes);


  app.use((err, req, res, next) => {
    console.error(err.stack);
    res.status(500).json({
      status: "error",
      message: err.message,
    });
  });


  app.listen(PORT, () => {
    console.log(`Server running on port ${PORT}`);
  });


  process.on("SIGINT", async () => {
    try {
      await mysqlConnection.end();
      await redisClient.quit();
      console.log("Database connections closed");
      process.exit(0);
    } catch (error) {
      console.error("Error during shutdown:", error);
      process.exit(1);
    }
  });
}


startServer();

create the product routes and the controllers with the functions:

Routes with endpoint for products

javascript
// routes/products.js
const express = require("express");
const router = express.Router();
const ProductController = require("../controllers/productController");


module.exports = (redisClient, mysqlConnection) => {
  const productController = new ProductController(redisClient, mysqlConnection);


  router.get("/", productController.getAllProducts.bind(productController));
  router.get("/:id", productController.getProduct.bind(productController));
  router.post("/", productController.createProduct.bind(productController));
  router.put("/:id", productController.updateProduct.bind(productController));
  router.delete(
    "/:id",
    productController.deleteProduct.bind(productController)
  );


  return router;
};

controllers with functions for updating products

utilised classes to use one connection for the database and to reduce the code base and avoid repitition of the connection:

javascript
class ProductController {
  constructor(redisClient, mysqlConnection) {
    this.redisClient = redisClient;
    this.mysqlConnection = mysqlConnection;
  }


  async getAllProducts(req, res) {
    try {
      const [products] = await this.mysqlConnection.execute(
        "SELECT * FROM products"
      );
      res.json(products);
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }


  async getProduct(req, res) {
    try {
      const { id } = req.params;


      // Check Redis cache
      const cachedProduct = await this.redisClient.get(`product:${id}`);
      if (cachedProduct) {
        return res.json(JSON.parse(cachedProduct));
      }


      // Get from MySQL
      const [products] = await this.mysqlConnection.execute(
        "SELECT * FROM products WHERE id = ?",
        [id]
      );


      if (products.length === 0) {
        return res.status(404).json({ message: "Product not found" });
      }


      const product = products[0];


      // Cache in Redis
      await this.redisClient.set(`product:${id}`, JSON.stringify(product));


      res.json(product);
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }


  async createProduct(req, res) {
    try {
      const { name, description, price, category, stock } = req.body;
      const id = Date.now().toString(); // Simple ID generation


      const [result] = await this.mysqlConnection.execute(
        "INSERT INTO products (id, name, description, price, category, stock) VALUES (?, ?, ?, ?, ?, ?)",
        [id, name, description, price, category, stock]
      );


      const [newProduct] = await this.mysqlConnection.execute(
        "SELECT * FROM products WHERE id = ?",
        [id]
      );


      res.status(201).json(newProduct[0]);
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }


  async updateProduct(req, res) {
    try {
      const { id } = req.params;
      const { name, description, price, category, stock } = req.body;


      const [result] = await this.mysqlConnection.execute(
        "UPDATE products SET name = ?, description = ?, price = ?, category = ?, stock = ? WHERE id = ?",
        [name, description, price, category, stock, id]
      );


      if (result.affectedRows === 0) {
        return res.status(404).json({ message: "Product not found" });
      }


      // Invalidate Redis cache
      await this.redisClient.del(`product:${id}`);


      const [updatedProduct] = await this.mysqlConnection.execute(
        "SELECT * FROM products WHERE id = ?",
        [id]
      );


      res.json(updatedProduct[0]);
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }


  async deleteProduct(req, res) {
    try {
      const { id } = req.params;


      const [result] = await this.mysqlConnection.execute(
        "DELETE FROM products WHERE id = ?",
        [id]
      );


      if (result.affectedRows === 0) {
        return res.status(404).json({ message: "Product not found" });
      }


      // Invalidate Redis cache
      await this.redisClient.del(`product:${id}`);


      res.json({ message: "Product deleted successfully" });
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }
}


module.exports = ProductController;
Tasks

Implement API routes for order?

Test the endpoints using Postman, curl or Thunder Client?

Explore swagger and other API documentation techniques?

Containerize this application and/or try deploying it?

Latest Articles

More Articles

Setting up jwt authentication, routes and a postgres connection

how to connect an express application to postgres and setup jwt authentication

January 30, 2025

Creating a server in node(Express)

creating servers using express

November 7, 2024
How can I help you architect your next project?

Njenga AI

System Assistant

👋 Hi! I'm Njenga, Kenneth's AI assistant. How can I help you today?
