What are APIs?

APIs(Application programming Interface) are a set of rules and protocols that defines how applications or devices interact. Think of it as a contract between the provider and the consumer.

They are tools that enable different software applications to communicate with each other. They're like translators that allow systems to exchange data and functionality seamlessly.

How APIs work:

APIs use requests and responses. A client sends a request, and the server processes it, returning the desired data or action.

Types of APIs:

REST (Representational State Transfer): Commonly used for web services, relies on HTTP methods like GET, POST, PUT, DELETE.

RESTFUL APIs explanation video

GraphQL: A newer option that allows clients to request specific data, reducing over-fetching or under-fetching.

GraphQl explanation video

SOAP (Simple Object Access Protocol): Older and more rigid, often used in enterprise application

WebSockets: Ideal for real-time data exchange, such as chat apps or live tracking.

websocket guide video

API Authentication:

Secure APIs often require authentication using tokens, such as API keys, OAuth, or JWT (JSON Web Tokens).

resources:

public-apis

Rapid api hub

Endpoints:

where resource can be located:

A visual depiction of what is being written about

Scheme (Protocol):

This is the first part of the URL, indicating the protocol used to access the resource.

Examples: http, https (for secure connections), ftp (file transfer), mailto (for email).

Host (Domain Name or IP Address):

The host specifies the location of the server where the resource resides.

It can be a domain name like example.com or an IP address like 192.168.1.1.

Example: www.example.com

Port (Optional):

Specifies the port number used by the server. If omitted, the default port for the protocol is used (80 for HTTP, 443 for HTTPS).

Example: :8080

Path:

The path points to a specific resource (e.g., a file or directory) on the server.

Example: /products/clothing/shirts

Query String (Optional):

This contains additional information in the form of key-value pairs, often used for filtering or searching.

It starts with a ? and separates key-value pairs with &.

Example: ?category=men&size=medium

Fragment (Optional):

A fragment identifies a specific section of the resource, often used with web pages.

It starts with # and links to an anchor tag or section on the page.

Credentials (Optional):

In some cases, credentials (username and password) may be included, though this is discouraged for security reasons.

HTTP methods/ CRUD operations

HTTP (Hypertext Transfer Protocol) methods are standardized request types used by clients to communicate with web servers. They define what kind of operation is intended for a resource on the server. Examples include GET, POST, PUT, DELETE, and others.

CRUD stands for Create, Read, Update, and Delete—the basic functions of persistent storage in databases or systems. CRUD represents the actions that can be performed on data

REST Principles

Stateless Communication: Every request from a client to a server must contain all the information needed to process the request. The server doesn’t store client context.

Resource-Based Design: REST focuses on resources (e.g., users, orders) identified by unique URIs. Resources are manipulated using HTTP methods.

Uniform Interface: REST provides a consistent set of rules for interaction, making APIs more predictable and easier to use.

Client-Server: Client handles UI and UX, server handles data storage and processing.

Cacheable: Responses from server can be cached by the client or intermediate proxies to improve performance.

continuation with commerce simulator to create /order routes apis

in controllers/folder create an orderController.js file

javascript
class OrderController {
  constructor(redisClient, mysqlConnection) {
    this.redisClient = redisClient;
    this.mysqlConnection = mysqlConnection;
  }

  async getAllOrders(req, res) {
    try {
      const [orders] = await this.mysqlConnection.execute(`
          SELECT o.*,
            GROUP_CONCAT(JSON_OBJECT(
              'product_id', oi.product_id,
              'quantity', oi.quantity,
              'price', oi.price
            )) as items
          FROM orders o
          LEFT JOIN order_items oi ON o.id = oi.order_id
          GROUP BY o.id
        `);

      // Parse the items string into JSON
      const formattedOrders = orders.map((order) => ({
        ...order,
        items: order.items ? JSON.parse(`[${order.items}]`) : [],
      }));

      res.json(formattedOrders);
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }

  async getOrder(req, res) {
    try {
      const { id } = req.params;

      // Check Redis cache
      const cachedOrder = await this.redisClient.get(`order:${id}`);
      if (cachedOrder) {
        return res.json(JSON.parse(cachedOrder));
      }

      const [orders] = await this.mysqlConnection.execute(
        `
          SELECT o.*,
            GROUP_CONCAT(JSON_OBJECT(
              'product_id', oi.product_id,
              'quantity', oi.quantity,
              'price', oi.price
            )) as items
          FROM orders o
          LEFT JOIN order_items oi ON o.id = oi.order_id
          WHERE o.id = ?
          GROUP BY o.id
        `,
        [id]
      );

      if (orders.length === 0) {
        return res.status(404).json({ message: "Order not found" });
      }

      const order = {
        ...orders[0],
        items: orders[0].items ? JSON.parse(`[${orders[0].items}]`) : [],
      };

      // Cache in Redis
      await this.redisClient.set(`order:${id}`, JSON.stringify(order));

      res.json(order);
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }

  async createOrder(req, res) {
    const connection = await this.mysqlConnection.getConnection();

    try {
      await connection.beginTransaction();

      const {
        total_amount,
        shipping_address_street,
        shipping_address_city,
        shipping_address_state,
        shipping_address_zip,
        shipping_address_country,
        items,
      } = req.body;

      const orderId = Date.now().toString(); // Simple ID generation

      // Create the order
      await connection.execute(
        `INSERT INTO orders (
            id, total_amount, shipping_address_street, shipping_address_city,
            shipping_address_state, shipping_address_zip, shipping_address_country
          ) VALUES (?, ?, ?, ?, ?, ?, ?)`,
        [
          orderId,
          total_amount,
          shipping_address_street,
          shipping_address_city,
          shipping_address_state,
          shipping_address_zip,
          shipping_address_country,
        ]
      );

      // Insert order items
      for (const item of items) {
        await connection.execute(
          `INSERT INTO order_items (order_id, product_id, quantity, price)
             VALUES (?, ?, ?, ?)`,
          [orderId, item.product_id, item.quantity, item.price]
        );
      }

      await connection.commit();

      const [newOrder] = await connection.execute(
        `
          SELECT o.*,
            GROUP_CONCAT(JSON_OBJECT(
              'product_id', oi.product_id,
              'quantity', oi.quantity,
              'price', oi.price
            )) as items
          FROM orders o
          LEFT JOIN order_items oi ON o.id = oi.order_id
          WHERE o.id = ?
          GROUP BY o.id
        `,
        [orderId]
      );

      const formattedOrder = {
        ...newOrder[0],
        items: newOrder[0].items ? JSON.parse(`[${newOrder[0].items}]`) : [],
      };

      res.status(201).json(formattedOrder);
    } catch (error) {
      await connection.rollback();
      res.status(500).json({ error: error.message });
    } finally {
      connection.release();
    }
  }

  async updateOrderStatus(req, res) {
    try {
      const { id } = req.params;
      const { status } = req.body;

      const [result] = await this.mysqlConnection.execute(
        "UPDATE orders SET status = ? WHERE id = ?",
        [status, id]
      );

      if (result.affectedRows === 0) {
        return res.status(404).json({ message: "Order not found" });
      }

      // Invalidate Redis cache
      await this.redisClient.del(`order:${id}`);

      const [updatedOrder] = await this.mysqlConnection.execute(
        `
          SELECT o.*,
            GROUP_CONCAT(JSON_OBJECT(
              'product_id', oi.product_id,
              'quantity', oi.quantity,
              'price', oi.price
            )) as items
          FROM orders o
          LEFT JOIN order_items oi ON o.id = oi.order_id
          WHERE o.id = ?
          GROUP BY o.id
        `,
        [id]
      );

      const formattedOrder = {
        ...updatedOrder[0],
        items: updatedOrder[0].items
          ? JSON.parse(`[${updatedOrder[0].items}]`)
          : [],
      };

      res.json(formattedOrder);
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }

  async deleteOrder(req, res) {
    try {
      const { id } = req.params;

      // Due to ON DELETE CASCADE, this will automatically delete related order_items
      const [result] = await this.mysqlConnection.execute(
        "DELETE FROM orders WHERE id = ?",
        [id]
      );

      if (result.affectedRows === 0) {
        return res.status(404).json({ message: "Order not found" });
      }

      // Invalidate Redis cache
      await this.redisClient.del(`order:${id}`);

      res.json({ message: "Order deleted successfully" });
    } catch (error) {
      res.status(500).json({ error: error.message });
    }
  }
}

module.exports = OrderController;

then in routes create an orders.js file

javascript
const express = require("express");
const router = express.Router();
const OrderController = require("../controllers/orderController");

module.exports = (redisClient, mysqlConnection) => {
  const orderController = new OrderController(redisClient, mysqlConnection);

  router.get("/", orderController.getAllOrders.bind(orderController));
  router.get("/:id", orderController.getOrder.bind(orderController));
  router.post("/", orderController.createOrder.bind(orderController));
  router.patch(
    "/:id/status",
    orderController.updateOrderStatus.bind(orderController)
  );
  router.delete("/:id", orderController.deleteOrder.bind(orderController));

  return router;
};

then in server or index.js or your server entry point:

javascript
app.use("/api/orders", orderRoutes);
const orderRoutes = require("./routes/orders")(redisClient, mysqlConnection);
